Cobra DLA112
The DLA112 is a lightweight, high SPL, single 12-inch array speaker. It features a low-distortion mid-bass unit, dual HF drivers with custom integrated waveguide and horn, precise coverage, uniform changes, three-point suspension, the whole system. installation is fast, stable and secure. Unit configuration: 1x12" high efficiency neodymium mid-bass unit, 2x1.4" output throat 44mm voice coil neodymium HF driver. The cabinet is made of multi-layer composite plywood with wear-resistant polyurea paint.
FREQUENCY RESPONSE(-3dB) - 60Hz-18KHz
FREQUENCY RESPONSE (-10dB) - 55KHz-20KHz
DRIVERS - 1×12"(300mm)/3" voice coil LF; 2×1"(36mm)/3.5" voice coil MF
NOMINAL POWER - 400W RMS, 1600W peak
Sensitivity - 98dB 1watt/1meter
MAX SPL - 122dB continuous, 128dB peak
MEMPEDANCE - 8 ohms nominal
DISPERSION(-6dB)- Horizontal Coverage: 90°
Vertical coverage: Varies depending on array length and configuration
CROSSOVER FREQUENCIES- 1.3KHz passive
INPUT CONNECTORS - 2×Speakon NL4
PACKAGE SIZE - 515mm×430mm×655mm
NET WEIGHT - 19 kg/pc
ENTIRE WEIGHT - 22 kg/pcHigh quality components, specially designed waveguide and horn ensure precise coverage angle and uniform changes
Passive way, simple operation, save amplifiers
Quick installation to hang, stack and support
Applications: multi-purpose halls, lecture halls, auditoriums, stadiums and tours
